Images used may not represent the actual product.
$337.23
The POR20-12FS-3K is a pilot operated relief valve from the POR20 Series with 3/4 in #12 female SAE ports. A relief valve limits the maximum pressure in a hydraulic circuit by opening a path to tank when system pressure reaches its setting.
In a pilot operated design, a small pilot stage senses system pressure and controls a larger main stage. When pressure reaches the pilot setting, the pilot opens and the main stage shifts to pass flow to tank. This lets a compact valve handle high flow while holding its setting more closely across the flow range than a direct acting valve of similar size.
The valve is rated for a minimum flow of 2 gpm and a maximum flow of 50 gpm. Maximum temperature is 180°F. Connections are female SAE straight thread ports in the #12 size, which corresponds to 3/4 in. SAE straight thread ports seal with an O-ring on the mating fitting, not on the threads.
The pressure setting is adjustable. Check the adjustment range against the working pressure of your circuit when you specify the valve, and set it with a gauge on the line. Order by the full part number POR20-12FS-3K so the port size, connection type and setting range match your system.
