$320.44
The LSV6-16-2NCSP is an L Series solenoid cartridge valve with a bi-directional, normally closed standard poppet. It is a 2-way, 2-position valve for a C16-2 cavity, rated at 22 gpm and 5,076 psi.
Normally closed means the valve blocks flow while the coil is off and opens when the coil is energized. Bi-directional means the closed valve blocks flow in both directions, not only one. This matters when pressure can arrive at either port.
The poppet closes against a seat, which keeps leakage low while the valve is closed. That makes a normally closed poppet a fit for functions that should stay in place with the power off.
The size 16 valve is rated at 22 gpm and 5,076 psi. The operating temperature range is -30°F to +250°F. The listed material is anodized aluminum alloy.
The product data does not list a coil voltage or connector. Confirm that your manifold is machined for a C16-2 cavity, select a coil that matches your control system, and check that flow and pressure stay inside the 22 gpm and 5,076 psi ratings before you order.
